Dimensions (L x W x H) | mm | 380 x 360 x 205 |
---|---|---|
Rated voltage | 220 - 240 V / 50/60 Hz | |
Power consumption | W | 20 - 198 |
Power cable length | m | 10.00 |
Net weight | kg | 11.00 |
Guarantee (+ request guarantee) | Years | 3 + 2 |
Max. flow rate | l/min | 333 |
Max. flow rate | l/h | 20000 |
Max. head height, metres | m | 4.50 |
Pressure-side connection | mm | 50 |
Pressure-side connection | 2" | |
Suction-side connection | mm | 50 |
Suction-side connection | 2" | |
Hose connection | mm | 25 / 32 / 38 / 50 |
Hose connection | 1", 1 ¼", 1 ½", 2" | |
Filter intake surface | cm² | 1300 |
Max. coarse debris displacement | mm | 11 |
Electronic adjustment | Yes | |
Setup type | Underwater installation only | |
Item number | 50708 | |
EAN | 4010052507088 |
